ADJ HEXCON L – 36‑Channel DMX Controller

ADJ HEXCON L – 36‑Channel DMX Controller

Description

Designed for wired digital communication networks, the HEXCON L is a hardware DMX controller built to operate up to six grouped LED fixtures (particularly the “HEX Series” RGBAL+UV LED fixtures) via DMX512. It features intuitive control with dedicated fixture buttons, multi‑function faders for color intensity and effects, and color macro/preset buttons for rapid look recall.

Key Specifications

• DMX Channels: 36

• Dedicated control for six fixture groups (channels set to e.g., 1, 7, 13, 19, 25, 31)

• 24 pre‑programmed color macro buttons

• 6 user‑programmable color preset buttons

• Multi‑function faders to control Red, Green, Blue, Amber, Lime, UV, master dimmer, strobe speed

• Function modes: Color Fade, Color Macro, Auto Run, Chase, Manual, Sound‑Active, Strobe, Blackout

• USB‑C port on main panel (to charge mobile devices)

• Power: 5 V DC 3 A (UL approved power supply included)

• Power consumption: approx. 15 W

• Dimensions: 14.2″ × 7.2″ × 2.7″ (360 × 183 × 69 mm)

• Weight: ~4 lbs (1.74 kg)
