AMX NCITE-813 8x1:3 4K60 4:4:4 Digital Video Presentation Switcher with HDCP 2.2, Video Scaling, Distance Transport, Advanced Windowing, DSP, Advanced Feedback Suppression

AMX Incite Digital Video Presentation Systems are next-generation presentation switchers that integrate AMX control and signal distribution with HARMAN audio. Video features include advanced windowing with scaling, supporting side-by-side, top-bottom, and picture-in-picture configurations, along with live production-style transitions. The systems support 4K/60 4:4:4 and HDCP 2.2, as well as lower resolutions, providing flexibility and compatibility with both legacy and modern source devices.

Audio capabilities include DSP with advanced functions such as independent 10-band parametric EQ, individual input gain control, variable compression, Advanced Feedback Suppression™, and, on two of the three models, DriveCore amplification technology.

Each system provides 8 inputs (4 HDMI, 2 DXLite, and 2 RGBHV/VGA) and delivers a scaled video feed to 2 local HDMI outputs and 1 DXLite output, making it an 8x1:3 presentation switcher. DXLite supports 4K/60 4:4:4 with visually lossless compression for cable runs up to 70 meters. DXLink Wallplate Transmitters can feed inputs into the system, while DXLite Receivers connect outputs to displays, projectors, or lecture devices.

Embedded audio processing allows switching between 6 embedded digital inputs, 6 analog stereo inputs, or 2 microphone inputs, which can be routed across 2 audio output groups. Outputs are available as 2 configurable balanced pre-amp outputs and as embedded audio on each of the 3 digital video outputs.

Control and configuration options include an integrated web GUI, front panel controls, On-Screen Menu Setup, and native NetLinx ICSP command support, with full feedback for system integration.

Common Applications
Ideal for university lecture halls, theaters, corporate and government boardrooms, and collaboration spaces, Incite provides professional video transitions, flexible windowing, compatibility with all source devices, and high-quality audio, making it perfect for high-use presentation environments.
