ATW-3211DE2

This is a 4th-generation “3000 Series” analog UHF wireless system. It consists of a rack-mountable true-diversity receiver and a body-pack transmitter (no microphone capsule included) designed for presenters, performers, houses of worship, lectures, etc.
It operates in the DE2 frequency band (470.125-529.975 MHz) and offers wide-band tuning to cope with congested RF environments.

Key Features

• Operates in a wide 60 MHz tuning bandwidth in the DE2 band (470-530 MHz range).

• Offers up to 2,395 selectable frequencies in that range.

• True-diversity reception on the receiver to reduce drop-outs.

• Auto-scan function on the receiver for selecting clear frequencies, plus IR-sync to match transmitter easily.

• Transmitter has selectable RF power output (10 mW or 30 mW) to trade off range vs interference/battery life.

• Body-pack transmitter: uses two AA batteries (alkaline or NiMH) with up to ~9.5 hours run time (low‐power mode) on NiMH.

• Body-pack has a cH-style screw-down 4-pin connector (for lavalier, head-worn, instrument cables) and includes a mute toggle switch.
