Description
RCF BD 2412EN — Overview & Key Features
-
The BD 2412EN is a bidirectional sound projector / loudspeaker, designed to project sound in two opposite directions for wide area coverage.
-
It complies with EN 54-24 standards, making it suitable for voice evacuation and emergency audio systems.
-
It has a rugged, weather-resistant design with IP66 protection, meaning it’s well sealed against dust and powerful water jets—usable outdoors.
-
Input power taps are available (for 100V line systems), commonly 20 W / 10 W / 5 W settings.
-
The unit uses aluminium housing, with a protective finish and grille, and is built for durability in harsh environments.
? Specifications & Performance
-
Frequency Response: ~ 130 Hz to 20,000 Hz
-
Max SPL @ 1 m: ~ 101 dB
-
Coverage Angle: ~ 130° in the horizontal plane
-
Sensitivity / Efficiency: ~ 88 dB (1 W @ 1 m)
-
Transducers: Dual 5-inch drivers (one on each side) to enable bidirectional projection
-
Mounting / Hardware: Comes with a mounting bracket (often a U-bracket) which allows for installation in corridors, tunnels, or along walls
-
Dimensions: Approximately 146 mm × 146 mm (front face) × 186 mm depth
-
Weight: ~ 3.2 kg (≈ 7.05 lbs)
