CGN99 C/S

An easy job

The CGN99 C/S and CGN99 C/L, part of the DAC Series, are condenser gooseneck microphones with a cardioid polar pattern. They are specially designed for inexperienced speakers who talk into the microphone from widely varying angles. The rugged gooseneck is available in two different lengths (C/S - 30cm (12in); C/L - 50cm (20in) and ideal for fixed and mobile installations. CGN99 C/S and CGN99 C/L come with an integrated XLR phantom power adapter with 250Hz bass rolloff. The phantom power adapter connects to any standard mixer input with 9V to 52V power supply.

General Specifications

Audio frequency bandwidth

70 - 18000 Hz

Equivalent noise level

21 dB-A

Signal to Noise

73 dB-A

Bass cut filter

250 Hz

Electrical impedance

600 Ohms

Recommended load impedance

2000 Ohms

Polar Pattern

Cardioid

Dimensions

Height

380 mm

Diameter

13.5 mm

Net Weight

160 g

Design

Finish

matte black

Audio Output

Type

Balanced XLR

Gender

Male

Contacts

3-pin

Powering Interface

Voltage

9 to 52 V

Current

3 mA

1 x CGN99C/S Microphone

1 x Windscreen
