DBX ZC3 EU Wall-Mounted Zone Controller

The Zone Controllers extend the capabilities of the DriveRack® and ZonePRO™ systems by providing versatile logic control via analog DC voltage. Across the nine available Zone Controllers, users can manage functions such as zone source selection, volume and muting, program or scene selection, and fire safety muting. Installation is simple and cost-effective, using standard CAT5 cabling with RJ-45 connectors, supporting distances up to 1,000 feet, making them a practical solution for contractors.

The ZC-3 serves as a programmable program selector for the dbx DriveRack 220i and 260, and can also function as a source selector, page steering controller, or scene selector for ZonePRO™ devices.

Architects’ and Engineers’ Specifications

The remote controller shall provide:

• Programmable rotary switch for program selection on DriveRack 220i and 260

• Rotary switch programmable source selection, page assignment, or scene selection for ZonePRO devices

• DIP switches for device identification

• Connection to the processing device via CAT5 cable with RJ-45 connectors

The unit shall be the dbx ZC-3-EU remote controller.

Specifications

• Connectors: (2) RJ-45

• Series Wiring: Maximum cable length depends on the number of Zone Controllers

  • 3 Zone Controllers: 600 ft

  • 6 Zone Controllers: 300 ft

• Parallel Wiring (using ZC-BOB): Up to 6 Zone Controllers: 1,000 ft

• Parallel Wiring Cable: CAT5 or CAT5E, 28.6 Ω/m nominal DCR, rated VW-1 or higher

• Safety Certifications: UL 60065, IEC 60065, EN 55013, E60065
