EAW MK8126iPL-WP BLACK

The EAW MK8126iPL-WP Black is a high-performance passive two-way loudspeaker designed for professional sound reinforcement and permanent installation applications. It is engineered to deliver clear, consistent audio while maintaining a compact and durable design. The speaker features an IP56-rated enclosure, allowing it to operate reliably in environments where dust and moisture may be present, making it suitable for both indoor and outdoor installations.

This loudspeaker incorporates an 8-inch low-frequency woofer and a high-frequency compression driver mounted on a constant-directivity horn. The system is designed with beamwidth-optimized crossover technology to ensure smooth transition between drivers and consistent coverage throughout the listening area. Its passive crossover network allows the system to be powered by a single amplifier channel while maintaining balanced frequency response and sound clarity.

Key Features

• Passive 2-way loudspeaker design for professional installation systems

• 300 W power handling with 8-ohm nominal impedance

• 8-inch low-frequency transducer with vented loading

• 1-inch exit compression driver with approximately 1.4–1.5 inch voice coil on a constant-directivity horn

• 120° horizontal × 60° vertical coverage for wide and consistent sound dispersion

• Maximum sound pressure level up to approximately 130 dB

• Operating frequency range approximately 65 Hz – 19 kHz

• Beamwidth-optimized crossover design to maintain consistent sound coverage

• Internal passive crossover network enabling single-amplifier operation

• User-rotatable horn for vertical or horizontal mounting configurations
