EAW MKD1294 BLACK

The EAW MKD1294 Black is a high-output installation loudspeaker designed for professional sound reinforcement in venues such as stadiums, theaters, houses of worship, and music clubs. It is engineered to deliver powerful, full-range audio with consistent coverage and high fidelity across large listening areas.

The loudspeaker uses dual low-frequency drivers combined with compression midrange and high-frequency drivers mounted on a large rotatable horn. This configuration provides controlled sound dispersion, improved low-frequency response, and clear mid- and high-frequency reproduction. The enclosure is constructed from durable Baltic birch and designed for permanent installations where reliability, acoustic performance, and flexible mounting are required.

Features

• 1200 W passive installation loudspeaker

• Dual 12-inch low-frequency cone drivers with 3-inch voice coils

• 2-inch exit compression midrange driver with 3.5-inch voice coil

• 2-inch exit compression high-frequency driver with 1.75-inch voice coil

• Frequency response: 47 Hz – 20 kHz

• Maximum sound pressure level up to 145 dB

• Nominal coverage pattern: 90° horizontal × 45° vertical

• Passive or bi-amp operating modes

• Beamwidth-matched crossover technology for improved frequency response and clarity

• Large-format rotatable horn for adaptable sound dispersion

• Baltic birch enclosure for durability and acoustic stability

• 12 M10 mounting points for flexible installation

• Terminal block input connection
