Description
The EAW QX564i‑WP WHITE is a high‑output, three‑way passive installation loudspeaker designed for demanding fixed audio applications such as arenas, performing arts venues, houses of worship, clubs, and large indoor/outdoor spaces. It delivers powerful, full‑range sound with broad and controlled coverage thanks to its engineered transducer layout and directivity pattern. The weather‑protected construction makes it suitable for indoor and outdoor use where dust and moisture resistance is required.
Key Features
High‑Output, Three‑Way System
-
1000 W power handling capability for strong output and headroom.
-
Bi‑amplified, three‑way design separates low, mid, and high frequencies for cleaner, more efficient performance.
Advanced Transducer and Coverage Configuration
-
Four Phase‑Aligned™ 12‑inch low‑frequency cone drivers arranged in vertical and horizontal pairs extend pattern control into the low end.
-
Mid/high compression drivers with a 60° horizontal × 45° vertical constant directivity horn for consistent coverage across large areas.
-
Full range response covers approximately 55 Hz to 19 kHz, delivering deep lows and clear highs.
