Logic Drive 2X – Power & Control Hub for Logic Fixtures

Overview

The Logic Drive 2X is a 1U rack-mountable (or wall-mountable) unit by Iluminarc/Chauvet that combines Power-over-Ethernet (PoE++) and lighting control to power and manage remote architectural fixtures seamlessly. It serves as a compact yet powerful hub for modern lighting installations

⚙️ Key Features

Dual PoE Outputs

• 2 RJ45 PoE++ ports, each delivering up to 92.5 W (IEEE 802.3 bt, Type 4/Class 8) – ideal for powering up to 2 Logic-series fixtures per port

Flexible Control Options

• Accepts DMX via 5-pin Phoenix or XLR, Art‑Net, sACN, and RDM/Art‑RDM over TCP/IP

• Includes 1 LOGIC Wall Con that can store and recall 8 scenes; supports up to 4 wall controllers per hub
