Martin ERA 800 Performance moving head fixture.

The Martin ERA 800 Performance is a high‑output, LED‑based moving‑head profile fixture designed for large‑scale entertainment, touring and rental applications. It combines a rugged build with advanced features in a relatively compact package.

 Key Features

• 800 W white LED engine rated at ~6,500 K producing around 34,000 lumens output.

• Zoom range of 7° to 56° (approx. 1:8 zoom ratio) for wide throw flexibility.

• CMY (Cyan/Magenta/Yellow) colour mixing system plus a dedicated 6‑slot colour wheel for rich and varied colour palettes, including pastel and saturated primaries.

• Variable CTO (colour‑temperature correction) allowing shifting from daylight white down toward tungsten white, giving extra flexibility in white light output.

• Full framing system (also called "curtain framing"): four independent framing blades that can cross the full beam and rotate approximately ±60°, allowing precise beam shaping and “gobo framing” effects.

• Two gobo wheels: one rotating/indexing gobo wheel (6 glass gobos + open) and one static gobo wheel (7 gobos + open) for morphing and static effects.

• Animation wheel (continuous bi‑directional rotation) for dynamic gobo movement.

• Iris (0‑100%) for beam narrowing/closing, and two prisms (4‑facet circular and 6‑facet linear) for beam splitting effects.
