MXR-1001 10.1" Modero X® Series G5 Retractable Touch Panel

MXR-1001 / 10.1" Modero X® Series G5 Retractable Touch Panel

The MXR-1001 is a premium retractable 10.1" touch panel that adds elegance and functionality to any meeting space. The panel remains flush with the table when not in use and glides up smoothly at the touch of a button or via NetLinx control, providing a space-saving solution that eliminates clutter while delivering high-end aesthetics.

Despite its thin, sleek design, the MXR-1001 is feature-packed. It includes the G5 graphics engine for smooth animations, a quad-core processor capable of running demanding applications, and edge-to-edge capacitive multi-touch glass. It also integrates a web browser and document viewers for real-time content access during meetings or lectures.

Common Applications:
The MXR-1001 is ideal for high-end boardrooms and executive briefing centers requiring:

• A premium, elegant interface that stays out of sight when not in use

• A clean, clear table surface

• Multiple user interfaces on the same table

Key Features:

• Hideaway Panel: Saves space and maintains premium styling by remaining flush when closed

• Reinforced Thin Panel: Sleek and thin design with a unique hinge that ensures sturdiness under user interaction

• Optimal Viewing: In-Plane Switching (IPS) delivers wide viewing angles and accurate color reproduction; patent-pending technology automatically elevates and tilts the display to the ideal angle

• Motorized & NetLinx-Controllable: Raise or lower the panel based on room occupancy, macros, or NetLinx events

• G5 Graphics Engine & Quad-Core Processing: Smooth gesturing, swiping, dynamic reordering, and high-speed animations for premium performance

• Simplified Enterprise Updates: Deploy and update touch panel files and firmware from a network URL

• Built-in Web Browser, Document Viewers, and Enzo Sharing: Access and present real-time content from the web, USB, or cloud storage apps

• Advanced Communication Technologies: Supports HD video conferencing, HD video streaming, and USB connectivity

• Adjustable Security Modes: Customizable security levels for access, networking, and communication

• Dynamic Data Display: Listview buttons allow scrolling, searching, and selecting entries from dynamic data sources such as phonebooks, call logs, or RSS feeds

*Product Update Notice: NFC and HF RFID features are no longer included in Modero X® Series Touch Panels shipping on or after October 1, 2017.

Specifications:

• Display Size (WH): 9.9" x 6.7" (252 mm x 170 mm), 12.0" (304 mm) diagonal

• Viewable Area (WH): 8.5" x 5.3" (217 mm x 136 mm), 10.1" (257 mm) diagonal

• Resolution: 1280x800

• Viewing Angle: Vertical ± 89°, Horizontal ± 89°

• Aspect Ratio: 16:9

• Touch Overlay: Projected capacitive, multi-touch support, max 3 simultaneous touches

• Graphics Engine: AMX G5

• Front Panel Components: Light Sensor, Proximity Detector, Camera, LED Indicators, Sleep button

• Operating Temperature: 32° F to 104° F (0° C to 40° C)

• FG Numbers: FG5968-56 (Black), FG5968-57 (Silver)
