The all-arounder

The RA4000 EW is a passive omnidirectional wide-band UHF antenna that can be used as a transmitting or receiving antenna for wireless microphones and in-ear monitoring systems. It operates in a frequency range from 470MHz to 952MHz, providing a covering angle of 360° and an antenna gain of 1dB. The RA4000 EW is built with passive technology and requires no powering. It works for short cable lengths up to 10m and supports a professional BNC connector. The antenna has waterproof construction and can be used for indoor and outdoor applications. Using the included universal stand adapter, the RA4000 EW can be mounted on floor stands with 3/8" or 5/8" screws.

General Specifications

Switching bandwidth (from/to)

470 to 952 MHz

Antenna gain

1 dBi

Covering angle

360 Grad

Dimensions

Length

220 mm

Width

38 mm

Net Weight

65 g

Antenna Input

Output current

0; 0; 0

RF Attenuation

0; 0; 0

Antenna Output

Amount

1

Type

BNC

Gender

Female

Note

RF output (50 Ohms)

Recommended load impedance

50 Ohms

Design

Body

plastic

Finish

black

1 x RA4000 EW antenna

1 x Stand adapter
