Soundcraft Vi Line Input Card Local Rack

Soundcraft RS2424SP – 8‑Channel Analog Line Output Card

Purpose:
Provides additional analog line outputs for Vi Series digital consoles and compatible Local Racks/Stageboxes.

Channels:

• 8 electronically balanced analog line outputs

Connectivity:

• Single 25-pin D-sub (female) connector

• 24-bit D/A conversion supporting sample rates up to 96 kHz (44.1, 48, 88.2, 96 kHz)

Output Specs:

• Adjustable or jumper-selectable output level: 7–26 dBu (fixed settings at 15/24 dBu)

• Output impedance: 40 Ω

• Maximum load: 600 Ω at +24 dBu

• THD+N: <90 dBFS (1 kHz, 30 dBFS, 15 dBu fixed)

• Crosstalk: <110 dB at 1 kHz

Form Factor:

• D21m double-width card (occupies two rack slots)

Compatibility:

• Vi Series consoles: Vi5000/7000, Vi6, Vi1, Vi1000/2000/3000

• Local Rack and Compact Stagebox (CSB)

Use Case:

• Expands output capacity for live sound, studio, or broadcast applications

• Allows flexible analog output distribution for FOH, monitor mixes, or recording feeds
