Soundcraft ViSB Optical MADI HD (singlemode)

Soundcraft RS2562SP ViSB Optical MADI HD Card (Singlemode)

Purpose:

• Provides a high-capacity 64×64 channel MADI link for Vi Stagebox systems over single-mode optical fibre.

• Ensures low-latency, reliable digital audio transport over long distances.

Specifications:

• Channels: 64 inputs and 64 outputs at 48 kHz

• Connectivity: Dual duplex SC fibre connectors for redundant, automatic failover

• Distance: Up to 10 kilometers using single-mode fibre (vs. 1.5 km for multimode)

• Clocking: Operates in slave mode, synchronizing to the incoming MADI stream from the console

• Form Factor: D21m double-width card (occupies two slots)

Compatibility:

• Vi Stagebox only

• Not compatible with Local Rack or Compact Stagebox

Use Case:

• Ideal for large-scale touring, broadcast, or fixed installations requiring long cable runs and electrical isolation
