ADJ UBL9H 9x20W RGBAL+UV LED Bar With Wired Digital Communication Network

ADJ UBL9H – 9x20W RGBAL+UV LED Bar with Wired Digital Communication Network

Product Description
The ADJ UBL9H is a professional 1-meter linear LED wash fixture designed for event production, stage lighting, architectural illumination, wall washing, uplighting, and atmospheric effects. Equipped with nine powerful 20W RGBAL+UV LEDs, it delivers vibrant color mixing, high color accuracy, and adjustable white light output. The integrated Lime LED technology enhances CRI performance for more natural color rendering, making it suitable for live events, installations, and broadcast environments.

Features

• 9 × 20W ultra-bright RGBAL+UV (Red, Green, Blue, Amber, Lime, UV) LEDs
• High CRI (>90) for accurate color reproduction
• Variable color temperature control from 2,300K to 9,900K
• Smooth RGBAL+UV color mixing
• 17° beam angle
• Long-life LEDs rated up to 50,000 hours
• Horizontal Magnetic Alignment system for seamless fixture alignment
• OLED display with 4-button menu navigation
• RDM (Remote Device Management) compatible
• 7 DMX channel modes: 6, 11, 13, 16, 18, 25, and 28 channels
• Individual pixel control with 3 controllable LED sections
• 5 operating modes:
• Auto Run
• Program Mode
• Sound Active
• RGBAL+UV Manual
• DMX-512 Mode
• Built-in microphone for sound-triggered effects
• 64 built-in color macros
• LED pulse and strobe effects
• Electronic dimming from 0–100%
• 6 selectable dimming modes
• 4 selectable dimming curves
