ADJ VS5 LED Video Wall Panel (5.95mm Pixel Pitch)

The ADJ VS5 is a professional-grade indoor LED video wall panel designed for live events, concerts, touring productions, houses of worship, clubs, corporate presentations, and rental/staging applications. Featuring a 5.95mm pixel pitch and high-brightness RGB LEDs, the VS5 delivers sharp visuals, vibrant colors, and reliable performance for large-format video displays. Its modular design allows multiple panels to connect seamlessly, creating scalable video walls of virtually any size while maintaining excellent image quality and ease of installation.

Features

• 5.95mm pixel pitch for high-resolution visual performance
• 3-in-1 RGB SMD2121 LED technology
• Brightness output of up to 1,000 nits
• High contrast ratio of 5,000:1
• Wide viewing angles of 160° horizontal and 140° vertical
• Four individually replaceable LED modules per panel
• Front and rear serviceable design for easy maintenance
• Magnetic module system for quick servicing
• Premium LED binning for consistent color reproduction
• Built-in NovaStar A5s receiving card
• PowerLock In/Out and DataLock In/Out connectivity
• Seamless panel alignment with precision locking system
• Integrated corner protection for safer transport and handling
• Temporary magnetic panel connection for one-person installation
• Brightness adjustment from 0–100% with 100 levels
• 14-bit grayscale processing for smooth color transitions
• Refresh rate up to 3840Hz for flicker-free camera performance
• Supports multiple input formats including HDMI, DVI, VGA, SDI, and Composite (via compatible processors)
• Lightweight aluminum cabinet construction
• Compatible with ADJ Vision Series rigging and flight case accessories
• Supports vertical hanging installations of up to 20 panels
• Long LED lifespan rated up to 50,000 hours
• Designed for temporary indoor installations and touring applications
