ADJ VSGSB – Ground Support Base for VS2, VS3, VS5 & EVS3 LED Video Panels

Description
The ADJ VSGSB is a professional ground support base designed for ADJ Vision Series LED video walls. It serves as the foundation of the Ground Support System, providing a stable and secure structure for freestanding LED video wall installations. When used with the VSGSLT Ground Support Ladder Truss, VSGSCSB Clamp Support Bar, VSRB1 Base Bar, and appropriate ballast, it supports LED video walls up to six panels high and unlimited width.

Features

• Compatible with ADJ VS2, VS3, VS5, and EVS3 LED video panels
• Forms the base of a freestanding Vision Series video wall support system
• Supports video walls up to 6 panels in vertical height
• Unlimited wall width capability when properly configured
• Heavy-duty aluminum extrusion and steel construction
• Matte black finish for professional production environments
• Includes 2 couplers and locking pins
• Designed for touring, rental, staging, and production applications
• Requires use with VSRB1 Base Bar and VSGSLT Ground Support Ladder Truss
• IP20 rated for indoor/dry-location use

Technical Specifications

• Length: 3 ft (0.91 m)
• Material: Aluminum Extrusion and Steel
• Maximum Vertical Stack: 6 Vision Series Panels
• Weight: 12 lbs (5.4 kg)
