Allen & Heath AES3 Input/Output Module – 4-In / 6-Out Digital Audio Expansion Card (AH-M-DL-AES4I6O-A)

Allen & Heath AES3 Input/Output Module (AH-M-DL-AES4I6O-A)

4-In / 6-Out Digital AES3 Expansion Card for dLive Systems

The Allen & Heath AH-M-DL-AES4I6O-A AES3 Input/Output Module is a flexible digital audio interface expansion card designed for use with dLive and compatible Allen & Heath systems. It provides a combination of 4 AES3 inputs and 6 AES3 outputs, allowing direct connection to external digital devices such as processors, amplifiers, recording systems, and broadcast equipment.

This module is part of the AES3 card range used to expand system routing options while maintaining high-quality, low-latency digital audio transmission.

Key Features

• 4-channel AES3 digital inputs
• 6-channel AES3 digital outputs
• Designed for dLive system I/O expansion
• Supports AES/EBU (AES3) digital audio standard
• Input sample rate conversion (SRC) from 32 kHz to 192 kHz
• Output sample rates switchable between 44.1 kHz, 48 kHz, 88.2 kHz, and 96 kHz
• Direct integration into dLive MixRack or control surface I/O slots
• Low-latency, high-integrity digital signal routing
• Suitable for live sound, broadcast, theater, and installed systems
• Enables clean digital feeds to external DSPs and audio networks

Product Overview

The AH-M-DL-AES4I6O-A expands system connectivity by providing a balanced mix of AES3 inputs and outputs, making it suitable for setups that require both external digital signal reception and distribution.
