Allen & Heath AH‑DX012 12‑Output Remote Output Expander

Allen & Heath AH-DX012 – DX012 Expander Rack

Description:
The Allen & Heath AH-DX012 DX012 Expander Rack is a professional 1U rack-mountable output expander designed to extend the output capabilities of Allen & Heath digital mixing systems, including dLive, Avantis, SQ, and AHM processors. It provides 12 XLR outputs with flexible configuration options, allowing users to switch between fully analog outputs or a combination of analog and AES digital outputs for maximum system versatility.

Engineered for both live sound and installed audio environments, the DX012 connects via a single Cat5e cable using a secure EtherCon port, enabling placement up to 100 meters away from the mixer for flexible system design. It supports redundant connections for increased reliability or cascade mode for expanding additional I/O units. With plug-and-play operation and automatic firmware synchronization, the DX012 ensures seamless integration into professional audio workflows.

Features:

• 12 XLR outputs configurable as:
• 12 analog line outputs
• 8 analog + 4 stereo AES outputs
• 4 analog + 8 stereo AES outputs
• Supports AES digital output with selectable sample rates (44.1kHz, 48kHz, 88.2kHz, 96kHz)
• 1U 19-inch rack-mount design with integrated rack ears
• Single Cat5e connection via locking EtherCon port (up to 100m distance)
• Secondary EtherCon port for redundant connection or daisy-chaining expanders
• Plug-and-play setup with automatic firmware updates
• Compatible with dLive, Avantis, SQ mixers, and AHM audio matrix systems
• Ideal for feeding IEM systems, amplifier racks, and distributed audio systems
• Designed for touring, broadcast, and fixed installation applications
