Chauvet Professional, MediaMaster Vision-SDI2 PCIe Card (2 SDI Inputs/Loop Outputs)(CHAMMMSDI2)

Chauvet Professional MediaMaster Vision-SDI2 PCIe Card (2 SDI Inputs / Loop Outputs) (CHAMMMSDI2)

Product Description
The Chauvet Professional MediaMaster Vision-SDI2 PCIe Card is a high-performance video capture card designed to expand MediaMaster VS2+ and VS4+ media server systems with professional SDI input capabilities. Installed through a PCIe slot, it provides two independent 3G-SDI inputs and two loop-through outputs, enabling seamless integration of live video sources into MediaMaster software environments. The card supports SD, HD, and 3G-SDI video formats, delivering reliable, low-latency video capture for live events, broadcast, virtual production, and multimedia applications.

Features

• Adds 2 independent 3G-SDI video inputs to MediaMaster VS2+ and VS4+ systems
• Includes 2 SDI loop-through outputs for signal monitoring or distribution
• Supports SD-SDI, HD-SDI, and 3G-SDI video standards
• Maximum capture resolution up to 2048 × 1556
• High-speed PCIe interface with up to 650 MB/s data transfer rate
• Supports simultaneous dual-channel video capture
• Compatible with a wide range of professional broadcast and live production video sources
• Multi-buffered architecture helps reduce tearing and improve video performance
• Frame buffer memory of 64 MB per channel (128 MB total)
• Designed for integration with Chauvet Professional MediaMaster software
• Compact half-size PCIe card design for easy installation
