ADJ Focus Spot 4Z Pearl LED Moving Head Spot Fixture

Description

The ADJ Focus Spot 4Z Pearl is a powerful and compact moving head spot fixture featuring a 200W cool white LED engine, motorized focus, and motorized zoom with an adjustable 11°–22° beam range. Designed with a sleek white exterior housing, this fixture delivers bright, precise lighting effects for live events, theaters, nightclubs, houses of worship, and permanent installations. Equipped with rotating GOBOs, vibrant color options, dual prism effects, and advanced DMX control features, the Focus Spot 4Z Pearl provides versatile creative possibilities in a lightweight and durable design.

Key Features

• Powerful 200W cool white LED engine with 50,000-hour lifespan
• Bright 7,000-lumen output for professional lighting applications
• Motorized focus for sharp projection control
• Motorized zoom with 11°–22° beam adjustment and 16-bit fine zoom control
• Two rotating prism effects:
  • 5-facet linear prism
  • 6-facet circular prism
• 8 dichroic colors plus white for versatile color effects
• GOBO wheel with 6 removable and rotatable aluminum GOBOs plus open
• GOBO shake effect for dynamic projection patterns
• Smooth 0–100% dimming with multiple dimming curves
• Multiple strobe speed options
• 16-bit fine pan, tilt, and zoom control
• Three DMX modes: 16, 18, and 22 channels
• RDM (Remote Device Management) support
• USB firmware update port for easy maintenance
• Locking power In/Out connections for power daisy chaining
• 5-pin DMX In/Out connections for reliable signal linking
• Compact and lightweight design with white housing

Technical Highlights

• Light Source: 200W Cool White LED Engine
• LED Life: 50,000 hours
• Light Output: 7,000 lumens
• Zoom Range: 11°–22°
• Color Wheel: 8 dichroic colors + white
• GOBO Wheel: 6 rotating/removable aluminum GOBOs + open
• Pan Movement: 540°/630°
• Tilt Movement: 270°
• Control Modes: DMX512, Internal Programs, RDM
• DMX Channels: 16/18/22 channels
• Dimming Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2
• Power Connection: Locking Power In/Out
• Voltage: Multi-voltage operation
• Weight: 23 lbs. (10 kg)
