ADJ Novastar MX30;All-In-One LED controller

ADJ NovaStar MX30 – All-in-One LED Display Controller

Product Description
The ADJ NovaStar MX30 is a professional all-in-one LED display controller that combines advanced video processing and LED screen control in a single unit. Designed for fixed installations, rental staging, virtual production, broadcast environments, corporate events, digital signage, and high-end LED display applications, it delivers exceptional image quality, low-latency performance, and flexible signal management. The MX30 supports multiple video input formats, advanced color calibration, HDR processing, and large-scale LED display control, making it an ideal solution for demanding visual applications.

Features

• All-in-one design integrating video processing and LED display control
• Maximum loading capacity of up to 6.5 million pixels
• Supports display resolutions up to 8192 × 7680 pixels
• 10 Gigabit Ethernet output ports for LED screen connectivity
• 2 × 10G optical fiber ports for long-distance signal transmission
• HDMI 2.0 input supporting up to 4K@60Hz
• HDMI 1.4 input
• DisplayPort 1.1 input
• Dual 3G-SDI inputs with loop-through capability
• Supports HDR10 and HLG (Hybrid Log-Gamma) for enhanced image quality
• Advanced Genlock synchronization for broadcast and virtual production environments
• Ultra-low latency operation
• Frame-rate adaptive technology supporting a wide range of refresh rates
• Up to 3 independent processing layers
• Full grayscale calibration for improved display uniformity
• 14-channel color correction for precise color adjustment
• Color replacement and color enhancement functions
• Supports irregular and creative LED screen layouts without rectangle restrictions
• Stores up to 128 customizable presets
• HDCP 2.2 compliant
• SPDIF digital audio output
• Cascading control capability for multi-device systems
• Built-in touchscreen interface for easy operation
• Compatible with NovaStar VMP (Vision Management Platform) software
• Supports SNMP, Art-Net, and central control protocols
• Can operate as an All-in-One Controller or Send-Only Controller
