MSRP: $249.99
$199.99
— You save $50.00

Description

TASCAM's DR-60DmkII, an update of the award winning DR-60D, is the audio recording solution for on-set filmmakers and videographers. The streamlined design fits perfectly under a DSLR camera rig, without relying on bulky recorders or the limited audio quality of the cameras microphone in. The DR-60DmkII is the next generation of 4-track solid-state recording, based on TASCAMs decades of recording innovation. The upgraded HDDA microphone preamps provide up to 64dB of gain, capturing every nuance of a performance. The DR-60DmkII is designed for low-noise operation, including soft touch buttons and dedicated gain controls. Multiple recording modes are available on the DR-60DmkII. Reach beyond the limited performance of your cameras audio to capture the other half of your film. At a cost less than competing preamps, the TASCAM DR-60DmkII is the ultimate 4-track recorder designed for filmmakers, television, live events and web broadcast.

Features:

  • Record to SD/SDHC card (Up to 32GB).
  • Simultaneously record up to 4 tracks.
  • Record Modes: MONO, STEREO, DUAL MONO, DUAL STEREO, 4-CHANNEL.
  • Recording format: 44.1/48/96kHz, 16 or 24-bit, WAV/BWF.
  • TASCAM HDDA microphone preamps wth 120dB EIN and 64dB of gain.
  • Recording levels can be adjusted independently for the 1/L, 2/R and 3-4 inputs.
  • Two combo XLR/TRS inputs support +4dBu mic/line level input.
  • Phantom power to channels 1/2 (24V or 48VDC on XLRF).
  • Plug-in power and high-output mic input supported on inputs 3-4.
  • CAMERA OUT connector.
  • CAMERA IN connector for sound monitoring from the camera.
  • Independent adjustable LINE OUT and HEADPHONE jacks for high-quality sound output.
  • 50mW/ch headphone amplifier.
  • Tripod mounting socket (bottom) and mounting screw attachment (top).
  • Handles protect the screen and can be used to attach a shoulder strap.
  • Soft-Touch Rubber Keys.
  • HOLD switch to prevent accidental operation.
  • QUICK button feature.
  • 128x64 pixel LCD with backlight.
  • USB 2.0 connection for high-speed transferring of files.
  • Mini USB cable included.
  • Operates on 4-AA batteries, an AC adapter (sold separately) or USB bus power.
  • Can extend battery life with BP-6AA battery pack (sold separately).
  • Dedicated remote control jack for the wired RC-10 remote control or RC-3F footswitch (both sold separately).
  • Internal mixer: PAN and LEVEL controls.
  • Low cut filter (40/80/120Hz).
  • Limiter (1/L and 2/R can be selected for linked operation).
  • Delay function for microphone distance adjustment (up to 150ms).
  • M-S decode functionSlate tone generator (AUTO/MANUAL).
  • Selectable duration of slate tone from four positions (0.5/1/2/3 sec, when auto-generated).
  • Selectable slate tone generation. (3 positions: OFF/HEAD/HEAD+TAIL, when auto-generated).
  • File naming format can be set to use a user-defined word or date.
  • Dual-recording function allows two files to be recorded simultaneously at different levels.
  • Auto-record function can automatically start and stop recording.
  • lPre-recording function allows the unit to record a 2 second sound buffer before recording is activated.
  • Self-timer function for solo recording.
  • New file starts recording automatically without interruption when maximum file size is reached.
  • Track incrementing function allows a recording to be split by creating a new file when desired.
  • Jump back and play function.
  • Equalizer function for playback, and level alignment function to enhance the perceived overall sound pressure.
  • Resume function to memorize the playback position before the unit is turned off.
  • MARK function up to 99 points per audio track.
  • DIVIDE function.

DR-60DMKII SPECIFICATIONS

Recording media SD card(64MB to 2GB), SDHC card(4GB to 32GB)
Recording format
WAV 44.1/48/96kHz, 16/24bit
BWF 44.1/48/96kHz, 16/24bit
Number of channels 4-channel (stereo x2)
Analog audio input
1/L, 2/R connectors
Connector XLR-3-31 (1:GND, 2:HOT, 3:COLD)/6.3mm(1/4")TRS standard jack
Set to "MIC / MIC+PHANTOM"
Input impedance 2k ohms
Phantom power 48V +/-4V(10mA/CH) / 24V +/-4V(10mA/CH)
Maximum input level 0dBu
Minimum input level -72dBu
MIC input gain TRIM MAX
LOW +11dB
MID +36dB
HIGH +52dB
HIGH+PLUS +64dB
Set to LINE
Input impedance 10k ohms or more
Standard input level +4dBu
Maximum input level +24dBu
3-4 connector
Connector 3.5mm (1/8") stereo mini jack (this connector can be supplied plug-in power)
Input impedance 10k ohms
Maximum input level +10dBV
Minimum input level -50dBV
MIC input gain TRIM MAX
LOW +3dB
HIGH +26dB
HI + PLUS +38dB
CAMERA IN connector
Connector 3.5mm (1/8") stereo mini jack
Input impedance 10k ohms
Standard input level -10dBV
Maximum input level +6dBV
Analog audio output
CAMERA OUT connector
Connector 3.5mm (1/8") stereo mini jack
Output impedance 200 ohms
Standard output level -50dBV
Maximum output level -30dBV
LINE OUT connector
Connector 3.5mm (1/8") stereo mini jack
Output impedance 200 ohms
Standard output level -10dBV
Maximum output level +10dBV
PHONES connector
Connector 3.5mm (1/8") stereo mini jack
Maximum output level 50mW + 50mW
USB
Connector Mini-B type
Format USB2.0 HIGH SPEED mass storage class
REMOTE
Connector 2.5mm TRS jack
Power Four AA batteries(Alkaline or NI-MH),
USB bus power,
Dedicated AC adapter(TASCAM PS-P515U, sold separately),
Dedicated external battery pack(TASCAM BP-6AA, sold separately)
Power consumption 5.4W
Continuous operation time 2ch WAV, 44.1kHz, 16bit rec
DR-60D
Alkaline batteries (EVOLTA) About 2:30 min (Phantom on)
About 4:30 min (Phantom off)
NI-MH batteries (eneloop) About 3:15 min (Phantom on)
About 5:00 min (Phantom off)
NI-MH batteries (eneloop pro) About 3:45 min (Phantom on)
About 6:00 min (Phantom off)
DR-60D+BP-6AA
Alkaline batteries (EVOLTA) About 5:30 min (Phantom on)
About 10:30 min (Phantom off)
NI-MH batteries (eneloop) About 7:30 min (Phantom on)
About 12:00 min (Phantom off)
NI-MH batteries (eneloop pro) About 9:30 min (Phantom on)
About 14:30 min (Phantom off)
Dimensions 133(W)93.2(H)78(D)mm (with the top adapter attached)
Weight 510g (not including batteries)
Operating temperature 0ÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌ´åÇÌÎÌÌÎÌÌ´åÇÌÎå«Ì´å¢C to 40ÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌ´åÇÌÎÌÌÎÌÌ´åÇÌÎå«Ì´å¢C
Standard accessories USB cable, warranty card, Owner's manual

Computer Compatibility
Windows
OS Windows XP, Windows Vista, Windows 7, Windows 8
CPU Pentium 300MHz or more
RAM 128MB or more
USB recommended: USB2.0
Macintosh
OS Mac OS X Jaguar (V10.2), Mac OS X Panther (V10.3), Mac OS X Tiger (V10.4),
Mac OS X Leopard (V10.5), Mac OS X Snow Leopard(V10.6.8), OS X Lion(V10.7),
OS X Mountain Lion(V10.8)
CPU Power PC, iMac, G3, G4 266MHz or more
64MB or more
USB recommended: USB2.0

Audio Performance
Frequency response 20-20kHz +0.5/-2dB(LINE IN or MIC IN to LINE OUT, Fs44.1k/48kHz, JEITA)
20-40kHz +0.5/-3dB(LINE IN or MIC IN to LINE OUT, Fs96kHz, JEITA)
Distortion 0.02% or less(LINE IN or MIC IN to LINE OUT Fs44.1k/48k/96kHz, JEITA)
S/N ratio 92dB or more(LINE IN or MIC IN to LINE OUT Fs44.1k/48k/96kHz, JEITA)
Equivalent input noise -120dBu or more
