Tascam DR-70D Portable Recorder For Dslr

SKU:
DR-70D
UPC:
043774031139
Availability:
Ships within 3-5 business days
Shipping:
Free Shipping
  • Tascam DR-70D 4-track Portable Recorder for DSLR
  • Tascam DA-6400DP 64 Track Audio Recorder With Dual Power (2 Inlets)
  • Tascam DA-6400DP 64 Track Audio Recorder With Dual Power (2 Inlets)
  • Tascam DA-6400DP 64 Track Audio Recorder With Dual Power (2 Inlets)
  • Tascam V/L-S5 2-Way 5" Powered Studio Monitor
MSRP: $399.99
$299.99
— You save $100.00

Description

The DR-70D from TASCAM is the ultimate audio recording solution for filmmakers. Four balanced XLR mic inputs meet the requirements of production sound, from professional users to indie DSLR shooters. The compact format can be mounted either above or below a camera, and a pair of built-in microphones can capture sound on-set. The interface is designed for quick adjustment, with additional features to keep recording levels under control. all four inputs have individual gain controls. Each input has a limiter and low cut filter available for controlling volume. The recorder has tripod mounts on the top and bottom of the unit, allowing it to be mounted on a camera, a follow-focus cage, or used standalone. Uniquely designed for the needs of filmmakers, television producers, advertisers, and documentarians, the DR-70D packs multitrack recording into a package compact enough to use with any camera.

Features:

  • Supports SD/SDHC/SDXC cards.
  • Maximum number of tracks recorded simultaneously: (4).
  • Recording modes: MONO, STEREO, 2MIX, DUAL MONO, DUAL ST, DUAL 2MIX.
  • Recording formats: 16/24-bit, 44.1k/48k/96k Hz (WAV/BWF).
  • TASCAM HDDA microphone preamps.
  • Input levels.
  • XLR/TRS inputs support +4dBu line level and phantom power (24V/48V).
  • Supports mics requiring plug-in power, and mics with high output (1-2).
  • CAMERA OUT jack.
  • CAMERA IN jack allows the DSLR camera audio to be monitored through the DR-70D.
  • High-quality audio output through the line output jack that is independent of the headphones jack.
  • Headphone jack with 20mW+20mW maximum output.
  • Tripod mounting threads (bottom), camera screw attachment and a shoe mount that can be attached and removed with a coin (top).
  • Handles on the front left and right sides protect the screen and can be used to attach a shoulder strap.
  • Transport and SLATE buttons are made of rubber.
  • HOLD switch prevents accidental operation.
  • 128x64-pixel graphic LCD with backlight.
  • High-speed transfer of files to a computer using USB 2.0.
  • Micro-B USB cable included.
  • Operates on (4) AA batteries, with an optional AC adapter (TASCAM PS-P515U) or USB cable provided with the unit (USB bus power).
  • BP-6AA external battery pack (sold separately) makes operation.
  • RC-3F footswitch or RC-10 wired remote control (both sold separately).
  • Built-in mixer can be used to adjust Pan and Level to mix output of (4) channels.
  • Low-cut filter with five settings (40/80/120/180/220 Hz) to be used to reduce unwanted air-conditioning noise and other low-frequency sounds.
  • Limiter function can automatically adjust excessive input levels (stereo-linking possible for 1/L and 2/R).
  • Delay function to adjust for distances between mics (+/150 ms).
  • Mid-side decoding function enables the use of mid-side stereo mics.
  • Slate tone functions (automatic/manual).
  • Selectable slate tone insertion points (recording start or recording start and finish when using the automatic slate function).
  • Playback can be skipped to the slate tone insert position using the DATA dial.
  • File name format can be set to use a user-defined word or date.
  • Dual recording function allows two files to be recorded simultaneously at different levels (second file at between 1 dB and 12 dB).
  • Can start a new file automatically when a maximum file size is reached to continue recording.
  • Track incrementing function allows a file to be split by creating a new file during recording when desired.
  • Resume function remembers the playback position when the unit is turned off.

DR-70D SPECIFICATIONS

Recording media SD card(64MB to 2GB), SDHC card(4GB to 32GB), SDXC card(48GB to 128GB)
Recording format
WAV 44.1k / 48k / 96k Hz, 16bit / 24bit
BWF 44.1k / 48k / 96k Hz, 16bit / 24bit
Number of channels 4-channel (stereo2, mono4)
Analog audio input
1/L, 2/R, 3/L, 4/R connectors
Connector XLR-3-31 (1:GND, 2:HOT, 3:COLD) / 6.3mm(1/4")TRS standard jack
Set to "MIC / MIC+PHANTOM"
Input impedance 2k ohms
Phantom power 48V +/-4V(10mA/CH), 24V +/-4V(10mA/CH)
Maximum input level 0dBu
Minimum input level -72dBu
MIC input gain TRIM MAX
LOW +21dB
MID +36dB
HIGH +51dB
HI + PLUS +63dB
Set to "LINE"
Input impedance 10k ohms or more
Standard input level +4dBu
Maximum input level +20dBu
1/2 connector
Connector 3.5mm(1/8")stereo mini jack (this connector can be supplied plug-in power)
Input impedance 10k ohms
Maximum input level +10dBV
Minimum input level -50dBV
MIC input gain TRIM MAX
LOW +3dB
MID +11dB
HIGH +26dB
HI + PLUS +38dB
CAMERA IN connector
Connector 3.5mm(1/8")stereo mini jack
Input impedance 10k ohms
Standard input level -10dBV
Maximum input level +6dBV
Analog audio output
LINE OUT connector
Connector 3.5mm(1/8")stereo mini jack
Output impedance 200 ohms
Standard output level -10dBV
Maximum output level +6dBV
CAMERA OUT connector
Connector 3.5mm(1/8")stereo mini jack
Output impedance 200 ohms
Standard output level -40dBV
Maximum output level -24dBV
PHONES connector
Connector 3.5mm(1/8")stereo mini jack
Maximum output level 20mW + 20mW
USB
Connector Micro-B type
Format USB2.0 HIGH SPEED mass storage class
REMOTE
Connector 2.5mm TRS jack
Power 4 AA batteries(Alkaline or NI-MH),
USB bus power,
Dedicated AC adapter(TASCAM PS-P515U, sold separately),
Dedicated external battery pack(TASCAM BP-6AA, sold separately)
Power consumption 5.0W
Continuous operation time 2ch WAV, 44.1kHz, 16bit rec
Phantom power not used
DR-70D Battery Life (hours:minutes)
Alkaline batteries (EVOLTA) About 6:00: When XLR/TRS input selecte(Phantom off)
About 3:30: When XLR/TRS input selecte(Phantom on)
About 11:00: When 3/4 MIC (Built-in Mic) selected
NI-MH batteries (eneloop) About 6:15: When XLR/TRS input selecte(Phantom off)
About 3:15: When XLR/TRS input selecte(Phantom on)
About 10:30: When 3/4 MIC (Built-in Mic) selected
NI-MH batteries
(eneloop pro)
About 7:45: When XLR/TRS input selecte(Phantom off)
About 4:45: When XLR/TRS input selecte(Phantom on)
About 14:15: When 3/4 MIC (Built-in Mic) selected
DR-70D + BP-6AA *BP-6AA is using the alkaline batteries (EVOLTA).
Alkaline batteries (EVOLTA) About 13:00: When XLR/TRS input selecte(Phantom off)
About 7:30: When XLR/TRS input selecte(Phantom on)
About 25:30: When 3/4 MIC (Built-in Mic) selected
NI-MH batteries (eneloop) About 12:45: When XLR/TRS input selecte(Phantom off)
About 7:45: When XLR/TRS input selecte(Phantom on)
About 24:45: When 3/4 MIC (Built-in Mic) selected
NI-MH batteries
(eneloop pro)
About 14:30: When XLR/TRS input selecte(Phantom off)
About 8:45: When XLR/TRS input selecte(Phantom on)
About 27:00: When 3/4 MIC (Built-in Mic) selected
Dimensions 6.65(W)2.2(H)4.2(D)in
169(W)55.2(H)106.5(D)mm
(with the top adapter attached)
Weight 1.37lb (including batteries) / 1.16lb (without batteries)
625g (including batteries) / 530g (without batteries)
Operating temperature 0 to 40ÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÎÌÌÎÌÌÎÌÌ´åÇÌÎÌÌÎÌÌ´åÇÌÎå«Ì´å¢C
Standard accessories USB cable,Camera attachment bracket screw hole covers6Owner's Manual (including warranty)

Audio Performance
Frequency response 20-20kHz +0.5/-2dB(LINE IN or MIC IN to LINE OUT, Fs44.1k/48k Hz, JEITA)
20-40kHz +0.5/-3dB(LINE IN or MIC IN to LINE OUT, Fs96kHz, JEITA)
Distortion 0.02% or less(LINE IN or MIC IN to LINE OUT Fs44.1k/48k/96k Hz, JEITA)
S/N ratio 92dB or more(LINE IN or MIC IN to LINE OUT Fs44.1k/48k/96k Hz, JEITA)
Equivalent input noise -120dBu or less

Computer Compatibility
Windows
OS Windows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1
CPU Pentium 300MHz or more
RAM 128MB or more
USB recommended: USB2.0
Macintosh
OS Mac OS X Jaguar (V10.2), Mac OS X Panther (V10.3), Mac OS X Tiger (V10.4),
Mac OS X Leopard (V10.5), Mac OS X Snow Leopard(V10.6.8), OS X Lion(V10.7),
OS X Mountain Lion(V10.8), OS X Mavericks(10.9)
CPU Power PC, iMac, G3, G4 266MHz or more
RAM 64MB or more
USB recommended: USB2.0
